Supports Time-Sensitive Networking (TSN) capabilities
Supports jumbo frames up to 9.5 KB
Auto MDI/MDIX crossover detection
IEEE 1588 protocol and 802.1AS support for precise time synchronization
Each port has a unique MAC address
Plug and play installation with broad system compatibility
Lifetime technical support
3-year manufacturer warranty
Applications:
Cloud computing, servers, industrial automation, workstations
Industrial automation including machine vision, process control, and sensor integration (industrial cameras, proximity sensors, displacement sensors, laser sensors, video sensors)
High-speed Ethernet data transmission for servers, soft routers, aggregation switches, and high-end devices
Suitable for database construction, smart city projects, AI, AI robotics learning, VMware virtualization, and other demanding environments
Certifications:
FCC
CE
RoHS
| Width | 14.8 |
| Height | 2.8 |
| NetWeight | 0.23 |
| Brand | EB-LINK |
| Model | THENETWORKCARD |
| Controller | Intel 1225-V (Original Intel Chip) |
| Interface Type | 4 x RJ-45 ports |
| Bus Type |
No reviews yet — be the first to review.
| PCI Express 3.1, 5GT/s x4, compatible with x8/x16 |
| Port Speed | Auto-negotiation at 2500/1000/100/10 Mbps |
| Supported Standards | IEEE 802.3 Ethernet interface for 2500BASE-T, 1000BASE-T, 100BASE-TX, and 10BASE-TE applications (802.3, 802.3u, 802.3bz, 802.3ab) |
| Form Factor | Full height and half height bracket options |
| Dimensions | Bracket length 120mm; Card length 109mm x width 69mm |
| Power Consumption | Maximum (specific value not provided) |
| Manufactured by | Shilangzhiguang Technology Co., Ltd. |
| Country of Origin | Made in China |
