Professional decoding chip with 90 scans per second speed
Durable high-rebound mechanical switch rated for 5 million actuations
Anti-interference data cable with 1.6m length
Able to read distorted and twisted barcodes
ABS eco-friendly shockproof and drop-resistant housing, withstands free fall from 1.2 meters
Optical and Scanning Performance:
Supported Barcode Types:
1D: Code128, EAN-8, EAN-13, UPC-E, UPC-A, Interleaved 2 of 5, Matrix 2 of 5, Industrial 2 of 5, Code39, Codabar, Code93, Code11, Code32, ISBN, ISSN, MSI Plessey, GS1-128, AIM128, etc.
2D: QR Code, Data Matrix, PDF417, Aztec, Micro QR, Micro PDF417, Maxicode, Hanxin
Electrical Specifications:
Communication Interface:
USB (HID Keyboard, Virtual COM Port)
Durability:
Operating Environment:
Physical Characteristics:
Applications:
Retail checkout (product barcodes, screen payments)
Warehousing and logistics (express delivery)
Medical industry (drug traceability, medical insurance codes)
Catering and hospitality (verification codes)
Membership cards
Bookstores and libraries (ISBN codes)
Entertainment venues (membership codes)
| Width | 10.8 |
| Height | 8.0 |
| NetWeight | 0.3 |
| Brand | Haoshun |
| Suitable for multiple industries | retail checkout, warehousing and logistics, medical, catering and entertainment |
| Image Sensor | 960×640 global CMOS |
No reviews yet — be the first to review.
| Illumination | White fill light with red positioning light |
| Scanning Speed | 90 frames per second |
| Scanning Modes | Button trigger, continuous scan, automatic sensing |
| Scanning Depth | 25mm to 350mm (QR code 20mil), 50mm to 320mm (EAN13 13mil) |
| Scanning Angle | 360° rotation, ±55° tilt and skew |
| Field of View | Horizontal 38°, Vertical 28° |
| Scanning Angle Recognition | 130°, wide-angle scanning with large depth of field |
| Charging Voltage | DC 5V ±0.5V |
| Operating Current | 180mA |
| Standby Current | 75mA |
| Shock Resistance | ABS eco-friendly housing, drop tested from 1.2 meters onto concrete (six faces) |
| Mechanical Switch Life | 5 million actuations (tested in Haoshun laboratory) |
| Temperature | -10°C to 50°C |
| Humidity | 5% to 95% non-condensing |
| Storage Temperature | -25°C to 65°C |
| Weight | 180g ±10g |
| Dimensions | 165mm × 97mm × 65mm |
| Packaging Dimensions | 19cm × 10.5cm × 7.8cm |
