Chaopin3 Giant Wave 120 DA120 CPU Cooler

Speed: 3000RPM±10%

Cooling: High-efficiency heat dissipation with large-size pure copper base plate

ARGB Lighting: Infinite loop ARGB lighting effects with high-gloss mirror finish cold head cover

Radiator: High heat capacity radiator with 27mm rounded corner waterway and thickened core for increased heat dissipation area

Tubing: High-pressure resistant and durable 350mm length water cooling tube

Compatibility: Supports mainstream platforms including Intel and AMD (LGA115X/1200/1700/1800/20XX, AM4/AM5)

Installation: User-friendly installation experience with upgraded pressure fasteners and universal screws for Intel and AMD platforms

Warranty: 3-year warranty for peace of mind

Dimensions: 82.5mm x 157mm x 27mm (LxWxH)

- TDP: 200W

- Tube Length: 350mm

- Radiator Size: 157×120×27mm (LxWxH)

- Radiator Material: Aluminum

- Cold Head Size: 82.5x70.5×54.5mm (LxWxH)

- Pump Speed: 3000RPM±10%

- Cold Head Interface: 3Pin

- Cold Head Rated Voltage: 12VDC

- Cold Head Rated Current: 0.28±0.03A

- Cold Head Power Consumption: 3.36W

- CPU Compatibility:

- Intel Platform: LGA115X/1200/1700/18XX/20XX

- AMD Platform: AM4/AM5

- Fan:

- Quantity: 1pcs

- Size: 120×120×25mm

- Bearing: Hydro Bearing

- Speed: 400~1800RPM+10%

- Airflow: 73.6CFM

- Air Pressure: 2.43mmH20

- Rated Voltage: 12VDC

- Rated Current: 0.23±0.03A

- Power Consumption: 3.24W

- Fan Interface: 4PinPWM

- Pump LED:

- Type: ARGB

- Interface: 5V3Pin

- Rated Current: 0.2A

- Power Consumption: 1W

- Fan LED:

- Type: ARGB

- Interface: 5V-3pin

- Rated Current: 0.2A

- Power Consumption: 1W

Warranty Period: 3 years

Note: AMD platform requires the use of the original backplate provided by the motherboard.
