Color Depth:
Supports 10-bit and 12-bit color depth
True 12-bit professional color depth
Supports HDR static and dynamic HDR
Audio Support:
Up to 32 audio channels
1536 kHz audio sampling rate
Automatic audio-video synchronization
Refresh Rate:
Supports up to 360Hz refresh rate at 1080P
Supports 240Hz at 4K resolution
Compatibility:
Compatible with devices featuring standard MiniDP and DP interfaces
MiniDP end supports Thunderbolt interface compatibility
Supports dual-way transmission (both ends can be input/output)
Compatible with laptops, desktops, all-in-one PCs, monitors, TVs, projectors, Surface series, and other DP-enabled devices
Does not support HDMI
Cable Construction:
Number of Copper Wire Cores: 5 groups of thickened pure copper cores
Connector:
MiniDP (male) to DP (male)
Supports 360° EMI shielding to ensure stable signal transmission in electromagnetic environments
Features:
Plug and play, no driver required
Dual-direction data transmission
Supports G-Sync and FreeSync vertical synchronization technologies to prevent screen tearing and stuttering
Supports 3D stereoscopic imaging technology
High dynamic range (HDR) for enhanced contrast and realistic image quality
Supports 130% BT.709 wide color gamut
Anti-interference design with multiple shielding layers and pure copper cores for stable and clear signal transmission
Supports multi-screen extension and duplication for efficient office and gaming use
Durable and flexible cable design with anti-oxidation and anti-pull properties
Packaging:
Environmentally friendly packaging
Notes:
All technical data and performance specifications are based on tests conducted by SAMZHE laboratory.
Ensure use with standard MiniDP and DP interfaces; non-standard DP interfaces are not supported.
DP connectors are reversible; no need to distinguish plug orientation.
Applications:
Connect laptops to monitors, TVs, or projectors for high-resolution display and multi-screen setups
Ideal for gaming, video editing, professional color grading, and office presentations
Supports high refresh rates and resolutions for smooth and detailed visuals
No reviews yet — be the first to review.
| Width |
| 16.3 |
| Height | 1.3 |
| NetWeight | 0.078 |
| Brand | SAMZHE |
| Product Name | Mini DisplayPort (MiniDP) to DisplayPort (DP) Cable |
| Model Numbers | MTP10, MTP15, MTP20 |
| Length Options | 1 meter, 1.5 meters, 2 meters |
| DisplayPort Version | DP 1.4 (backward compatible with DP 1.2) |
| Bandwidth | 32.4 Gbps total bandwidth |
| Core Material | Pure copper wire cores (0.20BC thickened pure copper core for lower loss and stable transmission) |
| Shielding | 4-layer shielding including aluminum-magnesium alloy mesh (128 strands), aluminum foil, pure copper ground wire, and tinplate shielding layer on connectors |
| Outer Jacket | Durable PVC with high flexibility, resistant to over 5000 bends |
| Cable Diameter | 5mm to 5.5mm depending on model |
| Wire Gauge | 32 AWG |
| Connector plating | Thickened nickel plating and gold plating for corrosion resistance |
| Connector Shielding | Tinplate shielding shell for EMI and EMC protection |
| Product dimensions (approximate) | 20.5mm x 12mm x 24.8mm x 41.2mm (manual measurement may have slight deviations) |
| Packaging type | Bag packaging |
